| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5072ZYSE6 | 4th generation new type compactor |
| Wheelbase (mm) | 3308 | — |
| Tire Specification | 7.00R16 steel-belted tire | — |
| Transmission | Wanliyang 5-speed gearbox | — |
| Engine Model | D20TCIF11 | China VI diesel engine |
| Engine Power (kW) | 93 | — |
| Overall Dimensions (L×W×H, mm) | 6860 / 6740 / 6565 / 6520 × 2060 / 2080 × 2900 | Different rear structures result in different overall lengths |
| Gross Vehicle Weight (kg) | 7360 | — |
| Rated Payload (kg) | 1515, 1580, 1365, 1430 | Varies with configuration |
| Curb Weight (kg) | 5650, 5800 | Certified based on actual vehicle weight |
| Body Effective Volume (m³) | — | — |
| Operation Mode | Electric / Manual / Remote | All three modes are standard equipment |
| Loading Cycle Time | 12–25 s | — |
| Unloading Time | ≤25 s | — |
